Ayon Audio - CD-35 II Signature

Das high-endige Allround-Genie von Ayon!

Als konsequente Fortsetzung des CD-3sx erweitert der CD-35 des Spektrum an Funktionalität bis zum Maximum!
CD-Wiedergabe, Native DSD über BNC mit 512x, sowie PCM Wandlung mit bis zu 768kHz und 32 Bit.

Absolute State-of-the-Art!

Und die Modularität ermöglicht eine Anpassung bzw. Erweiterung an Ihr Bedarfsprofil:
Preamp Option: Quad Electric Volume Control sowie 3x Line In erweitern den CD-35 zu einem SACD/CD-Spieler + Wandler mit integrierter Vorstufe die Ihresgleichen sucht!

Signature Option: Beamt den CD-35 in den Olymp der unübertrefflichen Musikwiedergabe durch Wandlung aller Signale in DSD sowie die Verwendung von Mundorf Silver/Gold Caps!

That's ayon!

Technische Daten:

• Gerätetyp: CD Spieler inkl DAC+Vorstufe
• Sampling-Rate: 768kHz/32Bit & DSD 11.2MHz/256
• Röhren-Analog: 2x 6H30 & 2x 5687
• Röhren-PSU: 1x GZ30
• Dynamik: > 120dB
• Output level @1 kHz / Rms - LOW: 0-2.5V variable oder 2.5V fixed
• Output level @1 kHz / Rms - HIGH: 0-5V variable oder 5V fixed
• Output impedance Single-Ended-RCA: ~ 300 Ohms
• Output impedance Balanced-XLR: ~ 300 Ohms
• Digital output: S/PDIF (RCA)
• Digital input: SPDIF, AES/EBU, BNC, I2S, USB 24/192, 3xBNC für DSD
• Analog input: 1x XLR In, 2x Line In (RCA)
• Analog output: RCA & XLR
• SNR: > 120 dB
• Frequenzgang: 20Hz-20kHz +/- 0.2dB
• THD @ 1kHz: < 0.002%
• IR Fernbedienung: Ja
• Abmessungen(BxTxH) cm: 48x39x12 cm
• Gewicht: 17 kg



Zitate Testbericht und Preisverleihung des Vorgängers highfidelity.pl:

Gerhard Hirt, the owner of Ayon Audio, has a different idea. He thinks that it is more important for as many people as possible to be able to buy a high-end product without ruining their family budget to the sixth generation. It is for them that he has prepared his new top- class source – a player that has been ostentatiously called the CD-35, even though it also normally plays SACDs.

Its secret lies in refined upsampling of PCM signal to DSD signal, the results of which have never been so good before. The device, which costs less than €10,000, can be freely placed next to players that are three times as expensive and it will not necessarily be the loser. The following are a must-read:

Krakow Sonic Society, meeting #105:

No. 151 2016 read HERE Test: No. 152 | December 2016, read HERE Award: GOLD Fingerprint

Testberichte download:



http://soundrebels.com/ayon-cd-35-english-ver/

http://www.ayonaudio.com/fileadmin/pdf/PDF_2017/HiFiCritic17_Ayon_final.pdf


Preise je nach Ausstattung !

Full-featured Tube Top Loader CD/SACD-Player
Class-A triode vacuum-tube output stage for single-ended & balanced operation

● Logical sequenced soft-start power up for extended tube life
● Warm up function
● 0dB negative feedback (of any kind)
● Ultra short signal path
● Simplest direct circuit path for purest musical sound and high reliability
● Low output impedance for driving long runs interconnect to an amplifier, and any tube or solid state power amp
● No solid state devices in the analog tube output (signal path )
● Minimal discrete wiring for optimum signal propagation
● No followers or buffers in the signal path
● No DC servo that degrades the signal
● High quality parts throughout
● Fully hand assembled to insure the highest level of craftsmanship
● Separate analog output stage for left and right channel
● The volume is controlled in the analogue domain
● DAC digital input - S/PDIF (RCA) , AES/EBU (XLR), I2S, BNC, USB, 3 x BNC for DSD;
● Digital output - S/PDIF (RCA)
● Ultra-low jitter internal clock generator


● 2 separate R-Core / Low noise – insulated power transformer for digital & analog
● Innovative power supply provides a high speed energy delivery on transients
● Separate and isolated power supplies over each stage of amplification
● Tube rectification for 6H30/5687 analog output stage
● Choke filtering for 6H30/5687
● Regulated DC filament supplies with soft start for 6H30/5687
● AC power line filter to avoid noise and hash from entering into the unit.
● 10 separate voltage regulators


● Selected, premium quality passive components used in all applications
● High speed & high quality audiophile grade coupling capacitors
● High quality special tube sockets with gold pins
● Superior capacitors
● High quality – RCA & XLR jack
● Gold-plated industrial grade PCB
