Beschreibung


The design of the HDA range draws upon all of Arcam’s experience as one of the UK’s most respected audio companies, to produce Arcam’s best performing range of audio products yet – using the best quality components and engineering practices, the HDA range is designed and built to give you years of listening enjoyment.

PA720 7 Kanal Endstufe:

Exceptional Power, Immersive Sound

The PA720 is a high-performance power amplifier that delivers 7 channels of efficient Class G amplification. With an impressive 140W per channel, the PA720 is designed to offer the greatest flexibility and power without compromising on control.

Featuring the best-in-class components including a toroidal based power supply, acoustically damped chassis, paralleled transistor output stages and exceptionally low levels of distortion, the PA720 masters the reproduction of music with all its originality and detail for an unmatched level of sound quality and clarity.

PRODUCT DETAILS

  • 7 Channel Power Amplifier
  • 7 x 100W Class G amplification (8ohm, 20Hz-20kHz, 0.2% THD)
  • Class G amplification with 20W of Class A operation
  • Toroidal transformer
  • Ethernet, RS232 control
  • Switchable RCA or balanced XLR inputs

Technische Daten

Gerätetyp 7-Kanal-Endstufe, Class G (die ersten 20 W in Class A)
Ausgangsleistung, 7 Kanäle 7 × 100 W an 8 Ω / 7 × 140 W an 4 Ω (20 Hz – 20 kHz, 0,2 % THD)
Ausgangsleistung, 5 Kanäle 110 W an 8 Ω / 175 W an 4 Ω (1 kHz)
Ausgangsleistung, 2 Kanäle 140 W an 8 Ω / 225 W an 4 Ω (1 kHz)
Klirrfaktor 0,002 % (80 % Leistung, 8 Ω, 1 kHz)
Eingänge Cinch oder XLR umschaltbar; Empfindlichkeit 800 mV (Cinch) / 1,6 V (XLR) für 50 W an 8 Ω; 10 kΩ
Rauschabstand 105 dB (A-bewertet, 50 W an 8 Ω)
Frequenzgang 20 Hz – 20 kHz ±0,05 dB
Netzteil Ringkerntransformator
Steuerung Ethernet, RS232
Leistungsaufnahme max. 1,5 kW; Leerlauf 90 W; Standby < 0,5 W
Abmessungen 433 × 177 × 425 mm (B × H × T, inkl. Füße, Regler und Klemmen)
Gewicht 18 kg

Änderungen vorbehalten.
