ROTOFON SPU CLASSIC N E

16% unter UVP

Preis:
Sonderpreis€ 699,00 UVP€ 830,00

inkl. MwSt. Versandkosten werden im Checkout berechnet.

Lagerbestand:
Ausverkauft

GPSR-Konformitätsinformationen

Allgemeine Informationen

CE-Kennzeichnung: Ja

Name: Ortofon

Adresse: Ortofon A/S, Stavangervej 9, DK-4900 Nakskov, Denmark

E-Mail: suppprt@ortofon.dk

Webseite: ortofon.com

Europäischer Hersteller: Ja

Name: Audio Tuning Vertriebs Gmbh

Adresse: Pro-Ject Audio Systems / Audio Tuning Wirtschaftspark A5 Mistelbach/Wilfersdorf Analogweg 1 2130 Mistelbach

E-Mail: https://www.audiotuning.com/kontakt/

Webseite: https://www.audiotuning.com/

Beschreibung

The SPU Classic NE provides the same sound reproduction properties as the SPU Classic GM E series

The SPU Classic NE is sold without the integrated headshell unit.
The SPU Classic NE is a Moving Coil (MC) cartridge with an elliptical stylus profile and provides more detailed sound reproduction and expansive imaging.
Listeners who wish to mount the SPU Classic NE on a traditional headshell may do so by using the SPU N adaptor.
Those with vintage SPU-type headshells can use the Classic NE to recreate an authentic and functional SPU cartridge. NB: Vintage SPU-type headshells are no longer available.



Technical data

Output voltage at 1000 Hz, 5cm/sec. - 0.2 mV
Channel balance at 1 kHz  < 1 dB
Channel separation at 1 kHz  > 20 dB
Channel separation at 15 kHz  > 10 dB
Frequency response - 20-20.000 Hz + 3/- 2 dB
Tracking ability at 315Hz at recommended tracking force *)  - 60 µm
Compliance, dynamic, lateral - 8 µm/mN
Stylus type - Nude Elliptical
Stylus tip radius - r/R 8/18 µm
Tracking force range - 3.0-5.0 g (30-50 mN)
Tracking force, recommended - 4.0 g (40 mN)
Tracking angle - 20°
*) Typical value

Internal impedance, DC resistance - 2.0 ohm
Recommended load impedance > 10 ohm
Coilwire material - High Purity Copper (OFC)
Cartridge colour - Black matte
Cartridge weight - 13 g

Download the SPU series datasheet

Download the SPU series brochure
